Nintendo Switch Specifications



  • Size 102mm x 239mm x 13.9mm (with Joy-Con attached)
  • Please note: 28.4mm at the thickest, from the tips of the analogue sticks to the ZL/ZR Button protrusions.
  • Weight Approx. 297g
  • (With Joy-Con controllers attached: 398g)
  • Screen Capacitive touch screen / 6.2 inch LCD / 1280x720 resolution
  • CPU/GPU NVIDIA customised Tegra processor
  • System memory 32 GB
  • Please note: a portion of this internal memory is reserved for use by the system.
  • Communication features Wireless LAN (IEEE 802.11 a/b/g/n/ac compliant) / Bluetooth 4.1 (TV mode only. A wired LAN connection is possible through the use of a commercially available wired LAN adapter.)
  • Video output Maximum resolution: 1920x1080, 60 fps
  • Please note: output via HDMI cable in TV mode. In tabletop mode and handheld mode, the maximum resolution is 1280x720, which matches the screen resolution.
  • Audio output Supports linear PCM 5.1ch
  • Please note: output via HDMI cable in TV mode.
  • Speakers Stereo
  • USB terminal  USB Type-C terminal
  • Used for charging or for connecting to the Nintendo Switch dock.
  • Headphone mic. jack Stereo output
  • Game card slot Exclusively for Nintendo Switch game cards.
  • microSD card slot Compatible with microSD, microSDHC and microSDXC memory cards.
  • Please note: an update via an internet connection is required to use microSDXC memory cards.
  • Sensors Accelerometer / gyroscope / brightness sensor
  • Operating environment Temperature: 5 - 35°C / Humidity: 20 - 80%
  • Internal battery Lithium ion battery / battery capacity 4310mAh
  • Please note: the internal battery cannot be removed. If the battery needs to be replaced, we plan to offer paid replacement via Nintendo Customer Support.
  • Battery life Battery life can last for more than six hours, but will vary depending on the software and usage conditions.
  • For example, The Legend of Zelda: Breath of the Wild can be played for roughly three hours on a single charge.
  • Charging time 3 hours approx.
  • Please note: this is the time taken to charge while the console is in sleep mode.


Source: nintendo.co.uk
